SIMATIC ET200SP HA
Extremely high availability
PROFINET redundancy (R1, S2, MRP)
Redundant Power supply (24VDC)
Redundant I/0 module
online site expansion and hot exchange of I0 modules
Running configuration (CiR and HCiR)
Extremely robust
40 to +70 ° C horizontal installation (+60 ° C vertical installation) meets G3 standards for Protective coating and corrosive gas testing (ISA-S71.04)
Meet the EMC requirements of NAMUR NE21
Operating above 4,000 meters above sea level
Conformal protective coating
Compact design
203x163x22,5mm(H x D x W)
Each I10 module can support up to 32 channels
Each site can support up to 56 1/0 modules
The cabinet channel density is high
Highly modular for maximum scalability
Full I/O capabilities
DI 24 V with sensor power cord and 1ms timestamp
High voltage DI/DQ, including transfer contact relays up to 230 VAC15 A
AI/AQ 0/4-20 mA with HART, thermocouple and RTDAIIAQ, potential difference 125VAC1150VDC
Fail-safe DI/DQ and AI modules for SIL 3
product
SIMATIC ET 200SP HA, digital input terminal module, DI 32X24VDC HA, for terminal block, H1, P0, color code CC00, channel diagnostics
Product Model 6DL1131-6GF00-0PK0
AL N
ECCN N
The country of origin is Germany
Lifecycle Delivery Release (P.M300)
Product Type Bus adapter module
